Sunrise in China -- aseptic, compact and intelligent integrated beverage filling machine
Aseptic filling machine realizes the balance of finished products in aseptic, compact and integrated beverage filling. On the one hand, buyers must be absolutely safe when using. Our aseptic filling can make every customer achieve a balance, and our company can let customers learn the corresponding level of microbial knowledge and proven technology application, Asahi aseptic filling machine can meet these requirements. We will deal with wet or dry sterilization according to customer's needs, with packing with weighing sensor or flowmeter, and high or low performance range. The flexibility and reliability of our aseptic filling machine are recognized by our partners, This is why bottling companies all over the world use aseptic filling line to provide first-class results under various conditions. Our filling production line technology, microbial detection and control technology, air purification, filling and sealing technology, automatic control technology, advanced equipment are applied in all directions, It is suitable for the production and filling of acid drinks and neutral non protein drinks, as well as some neutral protein drinks series. The equipment can maximize the filling process of drinks, maintain good nutrition, flavor and color of drinks, especially for the design diversification of some heat sensitive drinks, and reduce the cost of PET bottles, It is suitable for the production and filling of acid drinks and neutral non protein drinks, as well as some neutral protein drinks series. The equipment can maximize the filling process of drinks, maintain good nutrition, flavor and color of beverage products, especially diversify the design of some heat sensitive drinks, and reduce the cost of PET bottles, It is suitable for the production and filling of acid drinks and neutral non protein drinks, as well as some neutral protein drinks series. The equipment can maximize the filling process of drinks, maintain good nutrition, flavor and color of beverage products, especially diversify the design of some heat sensitive drinks, and reduce the cost of PET bottles, It completely provides space for beverage marketing
Technical parameters:
Product model KYWJF3510A KYWJF6518A C opacity 15000bph 27600bph | |
|---|---|
| Size | 11650x9250x4500 mm 14460x11750x4500 mm |
| Quality | 17200kg 30700kg |
| Bottle type | bottle type interchange； Diometer60~l 10mm; Height 150~320mm;容量 Volume 330?2000ml |
| Beverage type | Fruit particle Juice,Tea,Soda water.milk beverage etc |
| Sterilization | >6D |
| Inside the bottle sterilization liquid residue | <0.5mg/L |
| Aseptic period | 72 Hours(Depending on the product)洗,nosmall cleaning in the middle |
sunrise Main structural features?The whole machine adopts modular design, each function module combination for all-in-one computer for easy operation.?The whole machine adopts the isolation cover seal, high efficiency fan and aseptic filtration system to ensure that the internal space of positive pressure, sterile state.?Automatic detection, control and record the process of the system, can real time monitor and record the related processes of each link in production line. ?The disinfectant solution is rinsed in a tracking manner, , keep sterilization, sterilization thoroughly.? Imported high efficiency nozzle omni-directional sterile water bottles, effectively guarantee the disinfectant residual standard.? Non-contact filling valve, avoid crossing infection and can ensure safety.? Electromagnetic induction meter or weighing transducer accurate quantitative filling quantity.?Automatic CIP cleaning off cup structure to ensure the efficient, clean and convenient cleaning.? Cap by soaking sterilization, tunnel sterile water washing, sterilizing thoroughly.? Using AROL constant torque magnetic sealing head, The constant torque, to ensure sealing qualification rate.?The sealing transmission part USES the steam heat shield technology, effectively guarantee the sterile isolation of the region and the contaminated area. ?The moving parts of the machine and rotating mechanism adopts the liquid seal technology, guarantee the sterile area is not contaminated.The whole machine adopts external lubrication system, which is safe and convenient, and ensures long-term stability of lubrication effect
CIP, sip, cop, SOP and other cleaning and sterilization processes inside and outside the machine are fully automatic controlled, efficient, convenient and fast
